This is a 12V 24V 48V 500W pure sine wave power inverter which can generate 500W of continuous power and up to 1000W of power at peak times (peak time reserve capacity is useful if more energy is required to start an appliance than for its continuous running).
This is a pure sine wave type of inverter, which means that the 110 or 230V AC output harmonically follows a smooth sine wave and is almost identical to normal mains electricity. Pure sine wave output is far superior than square sine wave or modified sine wave output for running appliances. This is because:
It is suitable for a broader range of appliances (for example, appliances with electric motors can not be powered by modified sine wave inverters) It is more efficient compared to modified sine wave inverters.
This product comes with important protection and safety features, such as over-discharge, overload, overheating and short-circuit automatic shutdown.
The inverter also features a powerful USB port for faster charging of mobile phones, MP3 players and others mobile loads
Product parameters:
OUTPUT
OUTPUT VOLT
100/110/120/220/230/240VAC
CONTINUOUS POWER
500W
SURGE POWER
1000W
WAVEFORM
PURE SINE WAVE
FREQUENCY
50Hz/60Hz
AC REGULATION
LOW & HIGH 10%
Non-load Consumption
<7W
EFFICEINCY
>90%
INPUT
USB OUTPUTt
5V
DC VOLTAGE
LED DISPLAY POWER & FAIL STATUS
INPUT RANGE
10-15VDC 21-30V 40-60V 50-75V 60-90V
PROTECTION
WORKING INPUT
12VDC 24VDC 48VDC 60VDC 72VDC
FUSE
35A 20A 15A 35A 35A
Low battery alarm
10.5+0.3V 21+0.5V 42+0.5V 52.5+0.3V 63+0.3V
Low battery shut down
10+0.5V 20+0.5V 40+0.5V 50+0.5V 60+0.5V
Over voltage shut down
15.5+0.5V 30.5+0.5v 60+0.5v 77.5+0.5V
Over load shut down
600W OVER 10 SECOND
Over heating shut down
>75℃
Over Thermal
shut down the output
Working Temperature
BETWEEN -10℃ and +50℃
soft start
OTHER
DIMENSION(L*W*H)
235*146*66mm
INNER BOX DIMENSION
300*180*115mm
CARTON DIMENSION
580*305*380mm
NET WEIGHT
1.85±0.2KG
GROSS WEIGHT
20±1KG
PACKING
10PCS/CTN
